Bitumen Decanter / Asphalt Drum Melter

According to construction requirements, asphalt should be free of water and be heated to applicable temperature so as to ensure the construction quality. Therefore, the drummed asphalt must be removed from the drum first (known as asphalt-removing-from-drum operation), and then be dehydrated and heated. When its temperature reaches 120-160 ℃, the asphalt could be stored in a storage tank for future use.

Gaoyuan drummed asphalt melter is the perfect equipment for performing asphalt-removing-from-drum operations, because it has the advantages of high productivity, high thermal efficiency, compact structure, simple operation and easy removal. In addition, compared with similar products, our drummed asphalt melter produces less pollution to environment.

Technical Specifications of Drummed Asphalt Melter
Model DT6
Dimension (Transportation) (L × W × H) (m) 8.6×2.5×2.7
Productivity (t / h) (environmental temperature is 20 ℃) 4-6
Applicable barrel models various models of barreled asphalt at home and abroad.
Number that barrels can be loaded (barrels / trolley) 32
Capacity of asphalt oil tank (m3) 12
Heat capacity of conducting oil furnace (Kcal / h) 60×104
Electric equipment capacities (KW) 30
Equipment total mass (t) 15
Performance Parameters of Conducting Oil Fuel Furnace
Model DRY60
Rated heat quantity (KCAL / H) 60 ×104
Design pressure (Mpa) 1.0
Highest applicable temperature (℃) set according to technological requirements, generally ≤ 250
Electrical capacity (Kw) 22
Total mass (t) 5
Dimension (L × W × H) (M) 4.5×1.7×2.3

We at Gaoyuan are an experienced drummed asphalt melter manufacturer, located in China. In order to accommodate all your road maintenance applications, we also supply asphalt distributor, synchronous chip sealer, micro surfacing paver, and more. High quality and competitively priced, our products are very popular in Poland, Russia, Indonesia, Vietnam, Kazakhstan, Kyrgyzstan, Nigeria, Angola, Congo, among other countries.
If you have a need for any of our products, please feel free to contact us.
